DraftSight
DraftSight lets professionals create, edit, view, and markup 2D and 3D DWG, DXF, and DGN files, with seamless SOLIDWORKS integration and productivity tools like Dynamic Blocks and PowerTrim.
About DraftSight
- Create, edit, view, and markup 2D and 3D DWG, DXF, and DGN files with precision and efficiency.
- Supports advanced features like STEP import, DGN export, and enhanced visibility control for custom blocks.
- Integrates seamlessly with SOLIDWORKS and 3DEXPERIENCE platforms for streamlined collaboration and data management.
- Offers productivity tools such as Dynamic Blocks, PowerTrim, DrawCompare, and automatic layer assignment.
- Provides flexible licensing options, including named-user, network, and perpetual licenses.
- Includes a familiar AutoCAD-like interface, supporting LISP routines and custom scripts for easy transition.
- Enables 3D modeling, parametric constraints, and prototyping for manufacturing and laser cutting.
- Features a Block Structure Palette and enhanced Dimension Style Manager for simplified design workflows.
Technical Specifications
Platforms
Windows, macOS
Latest Version
DraftSight 2025
License Type
Subscription
Pricing
Professional
$299.00
Per year
- Create, view and edit DWG, DXF and DGN files
- Powerful and affordable 2D drafting for everyone
- Complete set of edit, design and automation tools (incl. Autolisp)
Premium
$599.00
Per year
- Manage large 2D drawing sets with Sheet Set Manager
- Save time with PDF Import and batch printing
- Advanced 2D drafting and 3D design with parametric constraints
Network
$399.00
Per year
- Activate simultaneous usage and compliance throughout the organization
- Complete technical support provided by SOLIDWORKS partners
- Save time with easy network license deployment
